Capri hydraulic glass door closer SH11073

没有此类产品
Details
Download

 Note:

•  There is a pair of hinges in each box, they are not identical and each has its specific position.
•  One hinge is Hydraulic and should be placed as the bottom hinge, with the adjustment screws facing up. The other hinge needs to be placed in the top position.
•  Select the correct packers depending on thickness of glass.
•  Do not make any adjustments to the hydraulic hinge prior to installing them on the door. They are intentionally loose to ease installation.
•  Fix the hinges to the door first.
•  Place packers under the door, centre the door in the opening and fix hinge to the sidelight or jamb.
•  Once fixed in position, open the door and adjust tension for correct closing force.
